SKU: WSZC70-JCS
JCS WSZC70 Zinc Plated Steel Hi-Grip Wing Screw Adjustment Range 50-70mm Band Width 13mm
JCS WSZC70 Zinc Plated Steel Hi-Grip Wing Screw Adjustment Range 50-70mm Band Width 13mm
Regular price
£0.90
ex VAT£1.08inc. VAT
Regular price
£5.28
Sale price
£0.90
ex VAT£6.34£1.08
inc. VAT
In stock
Price Break
10+
£0.80
19+
£0.76
29+
£0.75
39+
£0.74
49+
£0.73
74+
£0.72
99+
£0.68
199+
£0.67
249+
£0.66
499+
£0.65
999+
£0.63
Couldn't load pickup availability
Share this product
Description
Description
Zinc Plated Steel Hi-Grip Wing Screw: Specifically designed for frequently removed hoses, the unique dovetail locking and side lugs of the wing plate ensure excellent sealing and longevity. Used for a wide variety of domestic, automotive and industrial applications, the standard Hi-Grip hose clip is made from mild steel, electroplated, passivated and tested to EN9227. Hi-Grip general-purpose worm drive hose clips are widely regarded for their quality, durability and ability to withstand a great deal of abuse.
- Brand / Quality:
- JCS - High Quality
- Width:
- 13mm
- Min Adjustment Range:
- 50mm
- Max Adjustment Range:
- 70mm
Technical
Technical
| BS No. | 70 |
|---|---|
| Adjustment Range (mm) | 50-70mm |
| Adjustment Range (inch) | 2 - 2-3/4 inch |
| A | 13mm |
| B | 37mm |
| C | 12mm |
| D | 16mm |
| E | 13mm |
| F | 0.9mm |
| G | 24mm |
| Recommended Torque Nm | 6Nm |
| Recommended Torque lb-in | 54lb-in |
