Dry Sliding Strips
What is a dry sliding strip?
A dry sliding strip is a flat, thin bearing material used to create a low-friction sliding surface between two parts that move against each other. Instead of rolling elements such as balls or rollers, the strip provides a smooth, self-lubricating layer that lets one surface glide over another with little friction and wear. Dry sliding strips are mainly used in linear motion applications, such as machine slideways, guides, wear plates, and sliding tables, where parts move back and forth in a straight line.
The most common dry sliding strips are multi-layer composite materials. They combine a strong steel backing for support, a porous bronze layer for bonding and heat transfer, and a low-friction sliding layer that does the work. This construction gives the strength of steel with the slippery, self-lubricating properties of the sliding layer.
A typical composite dry sliding strip has:
- Steel backing - gives the strip strength, stiffness, and good load-carrying capacity, and makes it easy to cut, bend, and fix in place
- Porous bronze layer - a sintered bronze layer bonded to the steel, which anchors the sliding layer and helps conduct heat away from the sliding surface
- Sliding layer - a low-friction material, usually PTFE-based for dry running or POM-based for marginal lubrication, that forms the working surface
Key features:
- Low friction - allows smooth sliding movement with low resistance
- Self-lubricating - PTFE-based strips can run dry without oil or grease
- Maintenance-free or low maintenance - little or no lubrication needed during service
- No stick-slip - smooth start-up movement without juddering, important for precise positioning
- High load capacity - the steel backing supports high static and dynamic loads
- Compact design - thin strips save space compared with rolling element guides
- Easy to work - can be cut, drilled, bent, and bonded or screwed in place
- Wide temperature range - PTFE-based strips can work in very low and high temperatures
- Good chemical resistance - suitable for many environments where oils or greases are not wanted
In simple terms, a dry sliding strip is a thin, self-lubricating bearing layer that lets parts slide against each other smoothly, quietly, and with little or no maintenance.
Why are dry sliding strips essential?
Dry sliding strips are essential wherever parts must slide smoothly and reliably without the cost, space, or maintenance of rolling bearings or lubricated slideways. Sliding surfaces that rub metal against metal wear quickly, need regular lubrication, and can seize or judder. A dry sliding strip replaces the metal-to-metal contact with a low-friction, wear-resistant surface that keeps movement smooth for a long time.
Their main benefits are:
- Reduced friction and wear - protects sliding surfaces and extends component life
- Little or no lubrication - PTFE-based strips run dry, avoiding oil and grease that can attract dirt or contaminate products
- Lower maintenance - fewer lubrication points and fewer repairs reduce downtime
- Smooth, precise movement - no stick-slip, giving accurate positioning on machine slides and tables
- Space-saving - thin strips fit into compact designs where rolling guides would not fit
- Cost-effective - often a simpler and cheaper solution than linear guides or rolling bearings
- Quiet operation - sliding contact runs quietly with low vibration
- Clean running - ideal for food, packaging, textile, and other clean environments
- Easy repair and replacement - worn slideways and wear surfaces can be restored by fitting new strips
- Resistance to harsh conditions - suitable for wide temperature ranges, moisture, and many chemicals
These qualities make dry sliding strips important in a wide range of industries and equipment, including:
- Machine tools - slideways, gibs, carriages, and sliding tables on lathes, milling machines, and grinders
- Packaging and food machinery - guides, slides, and wear surfaces where clean running is needed
- Presses and metal forming - slide guides and wear plates
- Material handling - lifting equipment, telescopic arms, sliding forks, and conveyors
- Agricultural and construction machinery - sliding linkages, telescopic sections, and wear pads
- Automotive and transport - seat slides, sliding doors, and adjustment mechanisms
- Textile and printing machinery - guides and sliding components
- Doors, gates, and sliding panels - industrial doors, sliding gates, and panels
- Medical and laboratory equipment - clean, quiet sliding mechanisms
- Repair and refurbishment - restoring worn slideways and guide surfaces on older machines
The main types of dry sliding strips
Dry sliding strips are usually grouped by their construction and sliding layer material.
By sliding layer:
- PTFE composite strips - have a sliding layer of PTFE with fillers, bonded into a porous bronze layer on a steel backing. They are self-lubricating and maintenance-free, run dry with very low friction, and suit low to medium speeds, oscillating movement, and applications where lubrication is not possible or not wanted
- POM composite strips - have a sliding layer of POM (acetal) with small pockets in the surface that hold grease. They need an initial lubrication when fitted and then run with very little maintenance. They suit higher loads, less clean environments, and applications where some lubrication is acceptable, and are more tolerant of dirt and impacts than PTFE strips
- Lead-free strips - composite strips made without lead in the sliding layer, for applications that need lead-free materials, such as food machinery and equipment covered by environmental regulations
By construction:
- Steel-backed composite strips - the most common type, giving high load capacity, stiffness, and good heat dissipation
- Bronze-backed strips - use a bronze backing for better corrosion resistance in wet or marine environments
- Solid polymer strips - made entirely from engineering plastics such as PTFE, UHMW-PE, nylon, or POM. They are lightweight, corrosion resistant, and easy to machine, but have lower load capacity than steel-backed strips
- Filled PTFE slideway tapes - thin PTFE-based tapes bonded onto machine slideways to give a low-friction, stick-free surface
- Bronze strips with solid lubricant plugs - bronze plates with graphite or other solid lubricant inserts, used for high loads, slow movement, and high temperatures
By thickness and size:
- Thin strips - around 1 mm thick, used where space is very limited or for lining existing surfaces
- Medium and thick strips - around 1.5 mm to 3 mm or more, used where more wear allowance, strength, or load capacity is needed
- Standard sheets - supplied in sizes such as 100 × 500 mm or 200 × 500 mm, ready to be cut to the shape needed
How to choose the right dry sliding strip?
Choosing the right dry sliding strip means matching it to the load, speed, movement, environment, and how it will be fitted. Work through these points in order:
- Lubrication - choose a PTFE composite strip if the application must run dry or lubrication is not practical, and a POM composite strip if initial lubrication is acceptable and the application is dirty or heavily loaded
- Load - check the static and dynamic load ratings, and choose a steel-backed strip for high loads
- Speed and movement - consider the sliding speed and whether the movement is continuous, back and forth, or occasional. PTFE strips work very well at low speeds and with oscillating or start-stop movement
- Temperature - check that the strip suits the operating temperature. PTFE strips generally handle a much wider temperature range than POM strips
- Environment - consider dirt, dust, moisture, chemicals, and cleanliness requirements. POM strips with grease pockets tolerate dirt better, while PTFE strips are ideal for clean environments where grease is not wanted
- Counterface - make sure the surface the strip slides against is hard, smooth, and suitable for the strip material, as a rough or soft counterface will increase friction and wear
- Thickness - choose a thickness that fits the available space and gives enough strength and wear allowance
- Sheet size - choose a sheet size that allows the required parts to be cut with minimal waste
- Fixing method - decide whether the strip will be bonded with adhesive, screwed or riveted with countersunk fixings, or held in a groove or pocket
- Cutting and machining - check whether the strip will be cut, drilled, or bent to shape, and use suitable tools that do not damage or overheat the sliding layer
- Lead-free requirements - choose lead-free strips where regulations or food contact require them
- Quality and brand - choose strips from reputable bearing manufacturers and suppliers for consistent performance and long service life
FAQ - all you need to know about dry sliding strips
What is a dry sliding strip used for?
A dry sliding strip provides a low-friction, wear-resistant surface between two parts that slide against each other, such as machine slideways, guides, wear plates, and sliding tables.
What is the difference between PTFE and POM sliding strips?
PTFE strips are self-lubricating and run completely dry, with very low friction and no stick-slip. POM strips have grease pockets in the surface and need initial lubrication, but they handle higher loads, dirt, and impacts better.
Do dry sliding strips need lubrication?
PTFE composite strips do not need lubrication and are designed to run dry. POM composite strips should be lubricated when fitted, after which they need little or no further lubrication.
How do I cut a dry sliding strip?
Strips can be cut with shears, a fine-tooth saw, a guillotine, or water jet cutting. Cut from the sliding layer side where possible, remove any burrs, and avoid overheating the sliding layer.
How are dry sliding strips fitted?
They can be bonded with a suitable adhesive on the steel side, fixed with countersunk screws or rivets, or held in a groove or pocket. The mounting surface should be clean, flat, and free from grease before bonding.
Can I machine the sliding surface?
It is best not to machine the PTFE sliding layer, as it is very thin and machining can remove the working layer. Where adjustment is needed, it is usually better to shim or machine the mating parts instead.
What surface should a dry sliding strip run against?
It should run against a hard, smooth counterface, usually hardened or ground steel or another suitable metal. A rough or soft counterface will increase friction and wear.
Can dry sliding strips be bent?
Yes, steel-backed composite strips can usually be bent to a gentle radius. Bend them carefully with the sliding layer on the correct side, and avoid tight bends that could crack or damage the layers.
What causes dry sliding strips to wear out?
Common causes include overloading, high sliding speeds, rough or soft counterfaces, dirt and abrasive particles, overheating, and misalignment.
Can dry sliding strips replace linear guides?
In many applications, yes. Dry sliding strips are simpler, more compact, and more cost-effective, although rolling linear guides are usually better for very high speeds, very high precision, and long continuous travel.
