SKU: UCPX.14-44
UCPX14-44 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 2-3/4 inch Bore Insert
UCPX14-44 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 2-3/4 inch Bore Insert
Regular price
£121.77
ex VAT£146.12inc. VAT
Regular price
Sale price
£121.77
ex VAT£146.12
inc. VAT
In stock
Price Break
3+
£108.37
4+
£102.28
9+
£101.07
19+
£99.85
49+
£98.63
99+
£97.41
499+
£91.33
999+
£90.11
1999+
£88.89
2999+
£87.67
4999+
£85.24
Description
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 69.85mm = 2.75 (2-3/4) inch
- Style:
- UCPX
- Bolt Hole Centres:
- 229mm
Technical
Technical
| d | 2-3/4 inch |
|---|---|
| h | 88.9mm |
| a | 330mm |
| e | 229mm |
| b | 89mm |
| s2 | 51mm |
| s1 | 27mm |
| g | 35mm |
| w | 171mm |
| B1 | 77.8mm |
| n | 33.8mm |
| Bolt Size | M22 |
| Weight | 10.6 kg |
| Dynamic load | 5190 kgf |
| Static load | 4190 kgf |
