SKU: UCPX.11
UCPX11 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 55mm Bore Insert
UCPX11 Metric Two Bolt Cast Iron Pillow / Plummer Block Housing with 55mm Bore Insert
Regular price
£61.43
ex VAT£73.72inc. VAT
Regular price
Sale price
£61.43
ex VAT£73.72
inc. VAT
Equivalent to: MP55
In stock
Price Break
10+
£54.67
19+
£51.60
29+
£50.99
39+
£50.37
49+
£49.76
74+
£49.14
99+
£46.07
199+
£45.46
249+
£44.84
499+
£44.23
999+
£43.00
Couldn't load pickup availability
Description
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Equivalent: MP55
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 55mm
- Style:
- UCPX
- Bolt Hole Centres:
- 184mm
Technical
Technical
| d | 55mm |
|---|---|
| h | 69.8mm |
| a | 260mm |
| e | 184mm |
| b | 79mm |
| s2 | 36mm |
| s1 | 25mm |
| g | 30mm |
| w | 139mm |
| B1 | 65.1mm |
| n | 25.4mm |
| Bolt Size | M20 |
| Weight | 6.3 kg |
| Dynamic load | 4100 kgf |
| Static load | 3150 kgf |
| Rec max speed | 2800 rpm |
