SKU: UCPX.10-32
UCPX10-32 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 2 inch Bore Insert
UCPX10-32 Imperial Two Bolt Cast Iron Pillow / Plummer Block Housing with 2 inch Bore Insert
Regular price
£46.22
ex VAT£55.46inc. VAT
Regular price
Sale price
£46.22
ex VAT£55.46
inc. VAT
Equivalent to: MP2
In stock
Price Break
3+
£41.13
4+
£38.82
9+
£38.36
19+
£37.90
49+
£37.44
99+
£36.97
499+
£34.66
999+
£34.20
1999+
£33.74
2999+
£33.28
4999+
£32.35
Description
Description
|
UCPX or MP Series Plummer / Pillow Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Equivalent: MP2
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 50.8mm = 2 inch
- Style:
- UCPX
- Bolt Hole Centres:
- 171mm
Technical
Technical
| d | 2 inch |
|---|---|
| h | 63.5mm |
| a | 241mm |
| e | 171mm |
| b | 73mm |
| s2 | 36mm |
| s1 | 20mm |
| g | 27mm |
| w | 126mm |
| B1 | 55.6mm |
| n | 22.2mm |
| Bolt Size | M16 |
| Weight | 4.4 kg |
| Dynamic load | 3400 kgf |
| Static load | 2550 kgf |
| Rec max speed | 3100 rpm |
