SKU: UCHA206-19
UCHA206-19 Imperial Cast Iron Hanger Bearing Unit with 1-3/16 inch Bore Insert
UCHA206-19 Imperial Cast Iron Hanger Bearing Unit with 1-3/16 inch Bore Insert
Regular price
£16.89
ex VAT£20.27inc. VAT
Regular price
Sale price
£16.89
ex VAT£20.27
inc. VAT
In stock
Price Break
3+
£15.03
4+
£14.19
9+
£14.02
19+
£13.85
49+
£13.68
99+
£13.51
499+
£12.67
999+
£12.50
1999+
£12.33
2999+
£12.16
4999+
£11.82
Description
Description
UCHA200 Series Normal Duty Screw Conveyor Hanger Units: These bearing units are supplied with a fully sealed bearing insert fitted and includes a grease nipple to facilitate lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts can be removed from the housing for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, grub screw fixing
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 30.16mm = 1.187 (1-3/16) inch
- Style:
- UCHA
Technical
Technical
| d | 1-3/16 inch |
|---|---|
| h | 2-33/64 inch |
| w | 4-1/16 inch |
| b | 3-5/64 inch |
| c | 0 inch |
| a | 1-37/64 inch |
| s | G-3/4 |
| l | 3/4 inch |
| B | 1.5 inch |
| n | 0.626 inch |
| Bearing no | UC206-19 |
| Housing no | HA206 |
| Weight | 0.778 kg |
