NTN UCFL217D1 Metric Two Bolt Oval Cast Iron Flange Housing with 85mm Bore Insert - Allow 2-3 Days
NTN UCFL217D1 Metric Two Bolt Oval Cast Iron Flange Housing with 85mm Bore Insert - Allow 2-3 Days
Regular price
£221.63
ex VAT£265.96inc. VAT
Regular price
Sale price
£221.63
ex VAT£265.96
inc. VAT
In stock
Price Break
3+
£219.41
4+
£210.55
9+
£206.12
19+
£199.47
49+
£195.03
99+
£183.95
499+
£155.14
999+
£0.00
1999+
£0.00
2999+
£0.00
4999+
£0.00
Description
Description
|
UCFL or SFT Series 2 Bolt Oval Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the oval cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 85mm
- Style:
- UCFL
- Bolt Hole Centres:
- 248mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter | 85mm |
| H | 305mm |
| J | 248mm |
| A<sub>2</sub> | 36mm |
| A<sub>1</sub> | 24mm |
| A | 63mm |
| N | 25mm |
| L | 190mm |
| A<sub>0</sub> | 87.6mm |
| B | 85.7mm |
| S | 34.1mm |
| Fixing bolt | M22 |
| --- | Load rating |
| Dynamic load C<sub>r</sub> | 92 kN |
| Static load C<sub>0r</sub> | 64 kN |
| Fatigue load limit C<sub>u</sub> | 4.6 kN |
| --- | Unit information |
| Mass | 8.8 kg |
