SKU: UCFL215D1-NTN
NTN UCFL215D1 Metric Two Bolt Oval Cast Iron Flange Housing with 75mm Bore Insert - Allow 2-3 Days
NTN UCFL215D1 Metric Two Bolt Oval Cast Iron Flange Housing with 75mm Bore Insert - Allow 2-3 Days
Regular price
£155.11
ex VAT£186.13inc. VAT
Regular price
Sale price
£155.11
ex VAT£186.13
inc. VAT
In stock
Price Break
3+
£153.56
4+
£147.35
9+
£144.25
19+
£139.60
49+
£136.50
99+
£128.74
499+
£108.58
999+
£0.00
1999+
£0.00
2999+
£0.00
4999+
£0.00
Description
Description
|
UCFL or SFT Series 2 Bolt Oval Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the oval cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 75mm
- Style:
- UCFL
- Bolt Hole Centres:
- 225mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter | 75mm |
| H | 275mm |
| J | 225mm |
| A<sub>2</sub> | 34mm |
| A<sub>1</sub> | 22mm |
| A | 56mm |
| N | 23mm |
| L | 165mm |
| A<sub>0</sub> | 78.5mm |
| B | 77.8mm |
| S | 33.3mm |
| Fixing bolt | M20 |
| --- | Load rating |
| Dynamic load C<sub>r</sub> | 73.5 kN |
| Static load C<sub>0r</sub> | 49.5 kN |
| Fatigue load limit C<sub>u</sub> | 3.8 kN |
| --- | Unit information |
| Mass | 6 kg |
