SKU: UCFC.211-34
UCFC211-34 Imperial Four Bolt Cast Iron Round Flanged Housing with 2-1/8 inch Insert
UCFC211-34 Imperial Four Bolt Cast Iron Round Flanged Housing with 2-1/8 inch Insert
Regular price
£54.49
ex VAT£65.39inc. VAT
Regular price
Sale price
£54.49
ex VAT£65.39
inc. VAT
In stock
Price Break
3+
£48.50
4+
£45.77
9+
£45.23
19+
£44.68
49+
£44.14
99+
£43.59
499+
£40.87
999+
£40.32
1999+
£39.78
2999+
£39.23
4999+
£38.14
Description
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 53.98mm = 2.125 (2-1/8) inch
- Style:
- UCFC
- Pitch Circle Diameter:
- 150.02mm = 150.02 (5-29/32) inch
Technical
Technical
| d | 2-1/8 inch |
|---|---|
| a | 7-9/32 inch |
| P | 5-29/32 inch |
| e | 4-11/64 inch |
| i | 33/64 inch |
| L | 1-21/32 inch |
| s | 3/4 inch |
| j | 15/32 inch |
| k | 19/32 inch |
| g | 1-7/32 inch |
| f | 4.9213 inch |
| z | 1-13/16 inch |
| Bi | 2.1890 inch |
| n | 0.8740 inch |
| Bolt Size | 5/8 inch |
| Weight | 4 kg |
| Dynamic load | 3400 kgf |
| Static load | 2550 kgf |
