SKU: UCFC.211
UCFC211 Metric Four Bolt Cast Iron Round Flanged Housing with 55mm Insert
UCFC211 Metric Four Bolt Cast Iron Round Flanged Housing with 55mm Insert
Regular price
£43.32
ex VAT£51.98inc. VAT
Regular price
Sale price
£43.32
ex VAT£51.98
inc. VAT
In stock
Price Break
3+
£38.55
4+
£36.39
9+
£35.96
19+
£35.52
49+
£35.09
99+
£34.66
499+
£32.49
999+
£32.06
1999+
£31.62
2999+
£31.19
4999+
£30.32
Description
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 55mm
- Style:
- UCFC
- Pitch Circle Diameter:
- 150mm
Technical
Technical
| d | 55mm |
|---|---|
| a | 185mm |
| P | 150mm |
| e | 106.1mm |
| i | 13mm |
| L | 42mm |
| s | 19mm |
| j | 12mm |
| k | 15mm |
| g | 31mm |
| f | 125mm |
| z | 46.4mm |
| Bi | 55.6mm |
| n | 22.2mm |
| Bolt Size | M16 |
| Weight | 4 kg |
| Dynamic load | 3400 kgf |
| Static load | 2550 kgf |
