SKU: UCFC.210
UCFC210 Metric Four Bolt Cast Iron Round Flanged Housing with 50mm Insert
UCFC210 Metric Four Bolt Cast Iron Round Flanged Housing with 50mm Insert
Regular price
£14.69
ex VAT£17.63inc. VAT
Regular price
Sale price
£14.69
ex VAT£17.63
inc. VAT
In stock
Price Break
3+
£13.07
4+
£12.34
9+
£12.19
19+
£12.05
49+
£11.90
99+
£11.75
499+
£11.02
999+
£10.87
1999+
£10.72
2999+
£10.58
4999+
£10.28
Description
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 50mm
- Style:
- UCFC
- Pitch Circle Diameter:
- 138mm
Technical
Technical
| d | 50mm |
|---|---|
| a | 165mm |
| P | 138mm |
| e | 97.6mm |
| i | 10mm |
| L | 40mm |
| s | 16mm |
| j | 12mm |
| k | 14mm |
| g | 28mm |
| f | 110mm |
| z | 42.6mm |
| Bi | 51.6mm |
| n | 19mm |
| Bolt Size | M14 |
| Weight | 3 kg |
| Dynamic load | 2750 kgf |
| Static load | 2020 kgf |
