SKU: TS-N3/4-SE38-DUN
Dunlop 12BX15T N3/4 inch Sprocket for SE38 Tension Arm
Dunlop 12BX15T N3/4 inch Sprocket for SE38 Tension Arm
Regular price
£19.21
ex VAT£23.05inc. VAT
Regular price
Sale price
£19.21
ex VAT£23.05
inc. VAT
In stock
Price Break
10+
£17.10
19+
£16.14
29+
£15.94
39+
£15.75
49+
£15.56
74+
£15.37
99+
£14.41
199+
£14.22
249+
£14.02
499+
£13.83
999+
£13.45
Couldn't load pickup availability
Description
Description
Dunlop Tension Sprocket: The idler sprocket set is designed as a tensioning element for applications in chain drives. The idler sprocket runs on a self-lubricating ball bearing Type 2Z. We have a range of idler sprockets to suit standard roller chain pitch sizes from O6B-1 to 24B-1.
Benefits: Suitable for applications in temperature range from -40 deg C to +80 deg C
- Brand / Quality:
- Dunlop - Good Quality
- Thread Size:
- M20
- Number of Teeth:
- 15
- Part No:
- N3/4 inch
Technical
Technical
| Part No. | N3/4 inch |
|---|---|
| No of Teeth | 15 |
| W | M20mm |
| L | 100mm |
| A | 20mm |
| B | 11.1mm |
| C | 15mm |
| D | 91.63mm |
| Torque Hex Nut 0.5d | 172 Nm |
| Adjusting Range Track R | 38mm |
| Size SE | 38 |
| To Fit Roller Chain ANSI | 60 |
| To Fit Roller Chain DIN 8187 | ISO 12 B |
