SKU: TBS-DS-12B-23-DF
Drive-Flex 23 Tooth 12B Tapered Bore Double Simplex Sprocket 3/4 inch Pitch Chain - Allow 2-3 Days
Drive-Flex 23 Tooth 12B Tapered Bore Double Simplex Sprocket 3/4 inch Pitch Chain - Allow 2-3 Days
Regular price
£88.60
ex VAT£106.32inc. VAT
Regular price
Sale price
£88.60
ex VAT£106.32
inc. VAT
Equivalent to: 671-037 DS12B1-23TB 6DS23TL
In stock
Price Break
5+
£87.71
10+
£84.17
20+
£82.40
50+
£79.74
100+
£77.97
500+
£73.54
1000+
£62.02
Couldn't load pickup availability
Description
Description
Tapered Bore Double Simplex Sprockets: Small sprockets are usually manufactured from C45 Steel. These taper bore double simplex sprockets accept tapered locking bushes in a wide variety of shaft sizes to allow the end-user to easily fit the sprocket to the shaft with minimal effort and no machining.
Available in a comprehensive range of British Standard Simplex, Duplex and Triplex sizes. Pilot Bore variants available if required.
Benefits: Universal on the shelf stock - wide range of tapered locking bushes and shaft sizes available to choose from. Durable and hard-wearing.
Equivalent: 671-037 DS12B1-23TB 6DS23TL
Available in a comprehensive range of British Standard Simplex, Duplex and Triplex sizes. Pilot Bore variants available if required.
Benefits: Universal on the shelf stock - wide range of tapered locking bushes and shaft sizes available to choose from. Durable and hard-wearing.
Equivalent: 671-037 DS12B1-23TB 6DS23TL
- Brand / Quality:
- Drive-Flex - High Quality
- Number of Teeth:
- 23
- Pitch:
- 19.05mm = 0.75 (3/4) inch
- Item Type:
- BS European Standard
Technical
Technical
| No. of Teeth | 23 |
|---|---|
| Pitch Diameter dp | 139.9mm |
| Outer Diameter de | 149mm |
| Width B | 45mm |
| Hub Diameter N | 119mm |
| Chamfer C | 45mm |
| Tooth Radius r3 | 2mm |
| Tooth Width b1 | 19mm |
| Taper Bush Series | <a href="advanced_search_result.php?&keywords=2517+taperlock">2517<span style="color:blue"> Click Here</span></a> |
| Weight | 1.995 kg |
