SKU: TBS-DS-12B-21
21 Tooth 12B Tapered Bore Double Simplex Sprocket 3/4 inch Pitch Chain
21 Tooth 12B Tapered Bore Double Simplex Sprocket 3/4 inch Pitch Chain
Regular price
£62.08
ex VAT£74.50inc. VAT
Regular price
Sale price
£62.08
ex VAT£74.50
inc. VAT
Equivalent to: 671-036 DS12B1-21TB
In stock
Price Break
10+
£55.25
19+
£52.15
29+
£51.53
39+
£50.91
49+
£50.28
74+
£49.66
99+
£46.56
199+
£45.94
249+
£45.32
499+
£44.70
999+
£43.46
Couldn't load pickup availability
Description
Description
Tapered Bore Double Simplex Sprockets: Small sprockets are usually manufactured from C45 Steel. These taper bore double simplex sprockets accept tapered locking bushes in a wide variety of shaft sizes to allow the end-user to easily fit the sprocket to the shaft with minimal effort and no machining.
Available in a comprehensive range of British Standard Simplex, Duplex and Triplex sizes. Pilot Bore variants available if required.
Benefits: Universal on the shelf stock - wide range of tapered locking bushes and shaft sizes available to choose from. Durable and hard-wearing.
Equivalent: 671-036 DS12B1-21TB
Available in a comprehensive range of British Standard Simplex, Duplex and Triplex sizes. Pilot Bore variants available if required.
Benefits: Universal on the shelf stock - wide range of tapered locking bushes and shaft sizes available to choose from. Durable and hard-wearing.
Equivalent: 671-036 DS12B1-21TB
- Brand / Quality:
- Major Brand - High Quality
- Number of Teeth:
- 21
- Pitch:
- 19.05mm = 0.75 (3/4) inch
- Item Type:
- BS European Standard
Technical
Technical
| No. of Teeth | 21 |
|---|---|
| Pitch Diameter dp | 127.82mm |
| Outer Diameter de | 136mm |
| Width B | 45mm |
| Hub Diameter N | 107mm |
| Chamfer C | 45mm |
| Tooth Radius r3 | 2mm |
| Tooth Width b1 | 19mm |
| Taper Bush Series | <a href="advanced_search_result.php?&keywords=2517+taperlock">2517<span style="color:blue"> Click Here</span></a> |
| Weight | 1.435 kg |
