SKU: TBS-DS-10B-13
13 Tooth 10B Tapered Bore Double Simplex Sprocket 5/8 inch Pitch Chain
13 Tooth 10B Tapered Bore Double Simplex Sprocket 5/8 inch Pitch Chain
Regular price
£17.24
ex VAT£20.69inc. VAT
Regular price
Sale price
£17.24
ex VAT£20.69
inc. VAT
Equivalent to: 671-017 DS10B1-13TB
In stock
Price Break
10+
£15.34
19+
£14.48
29+
£14.31
39+
£14.14
49+
£13.96
74+
£13.79
99+
£12.93
199+
£12.76
249+
£12.59
499+
£12.41
999+
£12.07
Couldn't load pickup availability
Description
Description
Tapered Bore Double Simplex Sprockets: Small sprockets are usually manufactured from C45 Steel. These taper bore double simplex sprockets accept tapered locking bushes in a wide variety of shaft sizes to allow the end-user to easily fit the sprocket to the shaft with minimal effort and no machining.
Available in a comprehensive range of British Standard Simplex, Duplex and Triplex sizes. Pilot Bore variants available if required.
Benefits: Universal on the shelf stock - wide range of tapered locking bushes and shaft sizes available to choose from. Durable and hard-wearing.
Equivalent: 671-017 DS10B1-13TB
Available in a comprehensive range of British Standard Simplex, Duplex and Triplex sizes. Pilot Bore variants available if required.
Benefits: Universal on the shelf stock - wide range of tapered locking bushes and shaft sizes available to choose from. Durable and hard-wearing.
Equivalent: 671-017 DS10B1-13TB
- Brand / Quality:
- Major Brand - High Quality
- Number of Teeth:
- 13
- Pitch:
- 15.88mm = 0.625 (5/8) inch
- Item Type:
- BS European Standard
Technical
Technical
| No. of Teeth | 13 |
|---|---|
| Pitch Diameter dp | 66.32mm |
| Outer Diameter de | 73mm |
| Hub Diameter N | 50mm |
| Width B | 36.5mm |
| Chamfer C | 1.6mm |
| Tooth Radius r3 | 16mm |
| Tooth Width b1 | 9.2mm |
| Taper Bush Series | <a href="advanced_search_result.php?&keywords=1108+taperlock">1108<span style="color:blue"> Click Here</span></a> |
| Weight | 0.371 kg |
