SKU: SYF50TF-SKF
SKF SYF50TF Small Footprint Cast Iron Plummer Block with Grub Screw Insert 50mm
SKF SYF50TF Small Footprint Cast Iron Plummer Block with Grub Screw Insert 50mm
Regular price
£105.47
ex VAT£126.56inc. VAT
Regular price
Sale price
£105.47
ex VAT£126.56
inc. VAT
In stock
Price Break
10+
£93.87
20+
£88.60
30+
£87.54
40+
£86.49
50+
£85.43
75+
£84.38
100+
£79.11
200+
£78.05
250+
£77.00
500+
£75.94
1000+
£73.83
Description
Description
|
SKF Y-bearing Plummer Block Units with a Cast Housing: These units contain a grey cast iron housing with a grease fitting in the housing which allows it to be re-lubricated. This makes them suitable for bearing arrangements that operate in high levels of contamination, high speeds, high temperatures or relatively heavy loads. The housing design has a shortened base that contains two threaded holes in the support base. Benefits: Grease fitting allows re-lubrication |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 50mm
- Style:
- SYF
- Bolt Hole Centres:
- 101.6mm
Technical
Technical
| d | 50mm |
|---|---|
| A | 54mm |
| A1 | 34mm |
| B | 51.6mm |
| H | 114.5mm |
| H1 | 57.2mm |
| J | 101.6mm |
| L | 135mm |
| G | M16 |
| G1 | 25.5mm |
| s1 | 32.6mm |
| Static load Cr | 23.2 kN |
| Dynamic load Cor | 35.1 kN |
| Fatigue load limit Pu | 0.98 kN |
| Limiting speed | 4000 rpm |
| Weight | 2.2 kg |
| Housing | SYF510 |
| Insert | YAR210-2F |
