SKU: SYF35TF-SKF
SKF SYF35TF Small Footprint Cast Iron Plummer Block with Grub Screw Insert 35mm
SKF SYF35TF Small Footprint Cast Iron Plummer Block with Grub Screw Insert 35mm
Regular price
£77.30
ex VAT£92.76inc. VAT
Regular price
Sale price
£77.30
ex VAT£92.76
inc. VAT
In stock
Price Break
10+
£68.80
20+
£64.93
30+
£64.16
40+
£63.38
50+
£62.61
75+
£61.84
100+
£57.97
200+
£57.20
250+
£56.43
500+
£55.65
1000+
£54.11
Description
Description
|
SKF Y-bearing Plummer Block Units with a Cast Housing: These units contain a grey cast iron housing with a grease fitting in the housing which allows it to be re-lubricated. This makes them suitable for bearing arrangements that operate in high levels of contamination, high speeds, high temperatures or relatively heavy loads. The housing design has a shortened base that contains two threaded holes in the support base. Benefits: Grease fitting allows re-lubrication |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 35mm
- Style:
- SYF
- Bolt Hole Centres:
- 82.6mm
Technical
Technical
| d | 35mm |
|---|---|
| A | 45mm |
| A1 | 27mm |
| B | 42.9mm |
| H | 93mm |
| H1 | 47.6mm |
| J | 82.6mm |
| L | 103mm |
| G | M10 |
| G1 | 15mm |
| s1 | 25.4mm |
| Static load Cr | 15.3 kN |
| Dynamic load Cor | 25.5 kN |
| Fatigue load limit Pu | 0.655 kN |
| Limiting speed | 5300 rpm |
| Weight | 1.2 kg |
| Housing | SYF507 |
| Insert | YAR207-2F |
