SKU: SSUCT.210
SSUCT210 Metric Stainless Steel Take Up Unit Housing with 50mm Bore Stainless Insert
SSUCT210 Metric Stainless Steel Take Up Unit Housing with 50mm Bore Stainless Insert
Regular price
£85.96
ex VAT£103.15inc. VAT
Regular price
Sale price
£85.96
ex VAT£103.15
inc. VAT
Equivalent to: ST50
In stock
Price Break
3+
£76.50
4+
£72.21
9+
£71.35
19+
£70.49
49+
£69.63
99+
£68.77
499+
£64.47
999+
£63.61
1999+
£62.75
2999+
£61.89
4999+
£60.17
Description
Description
|
SSUCT or ST Series Stainless Steel Take up Units: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
Equivalent: ST50
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 50mm
- Style:
- SSUCT
Technical
Technical
| d | 50mm |
|---|---|
| o | 19mm |
| g | 16mm |
| p | 83mm |
| q | 49mm |
| s | 29mm |
| b | 86mm |
| K | 16mm |
| e | 102mm |
| a | 117mm |
| w | 149mm |
| j | 49mm |
| l | 37mm |
| h | 90mm |
| Bi | 51.6mm |
| n | 19mm |
| Weight | 2.5 kg |
| Dynamic load | 2750 kgf |
| Static load | 2020 kgf |
| Rec max speed | 3400 rpm |
