SKU: SSUCF.208-24
SSUCF208-24 Imperial Four Bolt Square Stainless Steel Flange Housing with 1-1/2 inch Bore Stainless Insert
SSUCF208-24 Imperial Four Bolt Square Stainless Steel Flange Housing with 1-1/2 inch Bore Stainless Insert
Regular price
£57.80
ex VAT£69.36inc. VAT
Regular price
Sale price
£57.80
ex VAT£69.36
inc. VAT
In stock
Price Break
3+
£51.45
4+
£48.55
9+
£47.98
19+
£47.40
49+
£46.82
99+
£46.24
499+
£43.35
999+
£42.77
1999+
£42.20
2999+
£41.62
4999+
£40.46
Description
Description
|
UCF or SF Series Stainless Steel 4 Bolt Square Housings: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 38.1mm = 1.5 (1-1/2) inch
- Style:
- SSUCF
- Bolt Hole Centres:
- 102mm
Technical
Technical
| d | 1-1/2 inch |
|---|---|
| a | 130mm |
| e | 102mm |
| i | 21mm |
| g | 16mm |
| L | 36mm |
| S | 16mm |
| Z | 51.2mm |
| Bi | 49.2mm |
| n | 19mm |
| Bolt | 14mm |
| Weight | 1.9 kg |
| Dynamic load | 2560 kgf |
| Static load | 1810 kgf |
