SKU: SSUCF.204-12
SSUCF204-12 Imperial Four Bolt Square Stainless Steel Flange Housing with 3/4 inch Bore Stainless Insert
SSUCF204-12 Imperial Four Bolt Square Stainless Steel Flange Housing with 3/4 inch Bore Stainless Insert
Regular price
£25.43
ex VAT£30.52inc. VAT
Regular price
Sale price
£25.43
ex VAT£30.52
inc. VAT
In stock
Price Break
3+
£22.63
4+
£21.36
9+
£21.11
19+
£20.85
49+
£20.60
99+
£20.34
499+
£19.07
999+
£18.82
1999+
£18.56
2999+
£18.31
4999+
£17.80
Description
Description
|
UCF or SF Series Stainless Steel 4 Bolt Square Housings: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 19.05mm = 0.75 (3/4) inch
- Style:
- SSUCF
- Bolt Hole Centres:
- 64mm
Technical
Technical
| d | 3/4 inch |
|---|---|
| a | 86mm |
| e | 64mm |
| i | 15mm |
| g | 12mm |
| L | 25.6mm |
| S | 12mm |
| Z | 33.3mm |
| Bi | 31mm |
| n | 12.7mm |
| Bolt | 10mm |
| Weight | 0.63 kg |
| Dynamic load | 1000 kgf |
| Static load | 630 kgf |
