SKU: SSUCF.202-10
SSUCF202-10 Imperial Four Bolt Square Stainless Steel Flange Housing with 5/8 inch Bore Stainless Insert
SSUCF202-10 Imperial Four Bolt Square Stainless Steel Flange Housing with 5/8 inch Bore Stainless Insert
Regular price
£42.82
ex VAT£51.38inc. VAT
Regular price
Sale price
£42.82
ex VAT£51.38
inc. VAT
In stock
Price Break
3+
£38.11
4+
£35.97
9+
£35.54
19+
£35.11
49+
£34.68
99+
£34.26
499+
£32.11
999+
£31.69
1999+
£31.26
2999+
£30.83
4999+
£29.97
Description
Description
|
UCF or SF Series Stainless Steel 4 Bolt Square Housings: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 15.88mm = 0.625 (5/8) inch
- Style:
- SSUCF
- Bolt Hole Centres:
- 64mm
Technical
Technical
| d | 5/8 inch |
|---|---|
| a | 86mm |
| e | 64mm |
| i | 15mm |
| g | 12mm |
| L | 25.6mm |
| S | 12mm |
| Z | 33.3mm |
| Bi | 31mm |
| n | 12.7mm |
| Bolt | 10mm |
| Weight | 0.63 kg |
| Dynamic load | 1000 kgf |
| Static load | 630 kgf |
