SKU: SRB15/3_15/45-TRAN
SRB15/3 15/45 Tooth Metric En8 Steel Bevel Gear Set 3:1 Ratio 1.5 MOD 20deg Pressure Angle
SRB15/3 15/45 Tooth Metric En8 Steel Bevel Gear Set 3:1 Ratio 1.5 MOD 20deg Pressure Angle
Regular price
£106.43
ex VAT£127.72inc. VAT
Regular price
Sale price
£106.43
ex VAT£127.72
inc. VAT
Equivalent to: SRB15/3
In stock
Price Break
10+
£94.72
19+
£89.40
29+
£88.34
39+
£87.27
49+
£86.21
74+
£85.14
99+
£79.82
199+
£78.76
249+
£77.69
499+
£76.63
999+
£74.50
Couldn't load pickup availability
Description
Description
Equivalent: SRB15/3
- Brand / Quality:
- Drive-Flex - High Quality
- Bore:
- G1: 8mm / G2: 14mm
- Number of Teeth:
- 15/45
- Pitch Circle Diameter:
- G1: 26.5mm / G2: 68.1mm
Technical
Technical
| Gear 1 - Pitch Module | 1.5 |
|---|---|
| Gear 1 - No. Teeth | 15 |
| Gear 1 - dp | 22.5mm |
| Gear 1 - A+V | 46mm |
| Gear 1 - dm | 19.3mm |
| Gear 1 - Bore | 8mm |
| Gear 1 - F | 10.5mm |
| Gear 1 - A | 22.6mm |
| Gear 1 - de | 26.5mm |
| Gear 1 - S | 0mm |
| Gear 1 - Lm | 11.7mm |
| Gear 2 - Pitch Module | 1.5 |
| Gear 2 - No. Teeth | 45 |
| Gear 2 - dp | 67.5mm |
| Gear 2 - A+V | 37mm |
| Gear 2 - dm | 45.3mm |
| Gear 2 - Bore | 14mm |
| Gear 2 - F | 10.5mm |
| Gear 2 - A | 29.6mm |
| Gear 2 - de | 68.1mm |
| Gear 2 - S | 2.4mm |
| Gear 2 - Lm | 20mm |
