SKU: SL7/8-RHP

RHP SL7/8 Two Bolt Cast Iron Pillow Block and 7/8 Bore Grub Screw Full Width Insert

RHP SL7/8 Two Bolt Cast Iron Pillow Block and 7/8 Bore Grub Screw Full Width Insert
£29.93 ex VAT£35.92inc. VAT
£29.93 ex VAT£35.92 inc. VAT
Sale Sold out

In stock

Price Break
10+ £26.64
19+ £25.14
29+ £24.84
39+ £24.54
49+ £24.24
74+ £23.94
99+ £22.45
199+ £22.15
249+ £21.85
499+ £21.55
999+ £20.95
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description

RHP SL Series Plummer / Pillow Housings: Supplied with a sealed full width bearing insert fitted in the housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation.
The inserts can be removed from the housings for future replacement as required.
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing
Brand / Quality:
RHP - High Quality
Inside Diameter:
22.23mm = 0.875 (7/8) inch
Style:
SL
Bolt Hole Centres:
3.866-4.339 inch
Technical
Bore 7/8 inch
L 5.472 inch
H 1.312 inch
H1 0.504 inch
H2 2.669 inch
J max 4.339 inch
J min 3.866 inch
G 0.375 inch
A 1.417 inch
A1 0.965 inch
B 1.343 inch
s 0.564 inch
s1 0.298 inch
d1 1.339 inch
Dynamic load Cr 14000 N
Static load Cor 7880 N
Rec max speed 6250 rpm
Insert <a href="advanced_search_result.php?keywords=1025-7/8G+insonly">1025-7/8G Click Here</a>
Casting group 3
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
