SKU: NTA4860-TRA4860
NTA4860 Needle Roller Cage Thrust Assembly with 2 TRA4860 Washers 3x3.75x0.1406 inch
NTA4860 Needle Roller Cage Thrust Assembly with 2 TRA4860 Washers 3x3.75x0.1406 inch
Regular price
£15.95
ex VAT£19.14inc. VAT
Regular price
Sale price
£15.95
ex VAT£19.14
inc. VAT
Equivalent to: NTC4860+TRA4860
In stock
Price Break
10+
£14.19
19+
£13.40
29+
£13.24
39+
£13.08
49+
£12.92
74+
£12.76
99+
£11.96
199+
£11.80
249+
£11.64
499+
£11.48
999+
£11.16
Description
Description
|
NTA Imperial Series Needle Thrust Bearings Complete: Needle roller cage thrust assemblies complete with 2 TRA series washers are a low profile high load thrust bearing assembly, they are made up of a uniform cage which reliably guides a large quantity of needle rollers, the rollers are slightly relieved towards their outer edge to enable uniform load distribution and prevents any edge damage occurence. Benefits: Cost effective thrust solution, wide range, low profile, high load bearing. |
Equivalent: NTC4860+TRA4860
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 76.2mm = 3 inch
- Outside Diameter:
- 95.25mm = 3.75 (3-3/4) inch
- Width:
- 3.57mm = 0.141 (9/64) inch
Technical
Technical
| d | 3 inch |
|---|---|
| D | 3.75 inch |
| Eb | 0.0806 inch |
| Dw | 3.09 inch |
| dw | 3.57 inch |
| Dynamic load | 26.96 kN |
| Static load | 172.10 kN |
| Limiting speed | 4400 rpm |
| Weight | 0.021792 kg |
| Washer | Dimensions |
| d | 3.000 inch |
| d1 | 3.75 inch |
| h min | 0.03 inch |
| h max | 0.032 inch |
| Pilot min | 2.997 inch |
| Pilot max | 3.000 inch |
| Dia to clear washer | 3.781 inch |
| Weight | 0.034 lbs |
