SKU: MST60-RHP
RHP MST60 Cast Iron Take Up Unit and 60mm Bore Insert
RHP MST60 Cast Iron Take Up Unit and 60mm Bore Insert
Regular price
£265.06
ex VAT£318.07inc. VAT
Regular price
Sale price
£265.06
ex VAT£318.07
inc. VAT
In stock
Price Break
10+
£235.91
20+
£222.65
30+
£220.00
40+
£217.35
50+
£214.70
75+
£212.05
100+
£198.80
200+
£196.15
250+
£193.50
500+
£190.84
1000+
£185.54
Share this product
Description
Description
|
RHP MST Series Cast Iron Take Up Housing Units: Take up type cast iron bearing unit supplied with a sealed heavy duty full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 60mm
- Style:
- MST
Technical
Technical
| Bore | 60mm |
|---|---|
| L | 222.5mm |
| L1 | 137.5mm |
| L2 | 21.5mm |
| L3 | 32mm |
| L4 | 120.5mm |
| L5 | 77mm |
| H | 166.5mm |
| H1 | 113mm |
| H2 | 70mm |
| H3 | 150.8mm |
| N | 42mm |
| A | 70mm |
| A1 | 50.5mm |
| A2 | 27mm |
| B | 74.63mm |
| B5 | -mm |
| s | 30.23mm |
| d1 | 87mm |
| d4 | -mm |
| Dynamic load | 61000 N |
| Static load | 45000 N |
| Rec max speed | 2450 rpm |
| Weight | 7.9 kg |
| Insert | <a href="advanced_search_result.php?keywords=1070-60G+insonly">1070-60G Click Here</a> |
| Casting group | 8 |
| Grease nipple thread | 1/4 UNF, 1/4mm x 28 TPI |
