SKU: MFC3-RHP

RHP MFC3 Four Bolt Round Cast Iron Flanged Bearing Unit and 3 inch Insert

RHP MFC3 Four Bolt Round Cast Iron Flanged Bearing Unit and 3 inch Insert
Regular price £316.78 ex VAT£380.14inc. VAT
Regular price Sale price £316.78 ex VAT£380.14 inc. VAT
Sale Sold out

In stock

Price Break
10+ £281.94
20+ £266.10
30+ £262.93
40+ £259.76
50+ £256.59
75+ £253.43
100+ £237.59
200+ £234.42
250+ £231.25
500+ £228.08
1000+ £221.75
Quantity
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Technical
Bore 3 inch
L 8.748 inch
H 6.375 inch
J 7.5 inch
G 0.625 inch
A1 2 inch
A4 0.657 inch
A5 0.5 inch
B 3.25 inch
s 1.314 inch
d1 3.878 inch
Dynamic load 71500 N
Static load 54500 N
Rec max speed 2150 rpm
Weight 5.4 kg
Insert <a href="advanced_search_result.php?keywords=1080-3G+insonly">1080-3G Click Here</a>
Casting group 9
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
