SKU: MFC2-RHP
RHP MFC2 Four Bolt Round Cast Iron Flanged Bearing Unit and 2 inch Insert
RHP MFC2 Four Bolt Round Cast Iron Flanged Bearing Unit and 2 inch Insert
Regular price
£141.52
ex VAT£169.82inc. VAT
Regular price
Sale price
£141.52
ex VAT£169.82
inc. VAT
In stock
Price Break
10+
£125.95
20+
£118.88
30+
£117.46
40+
£116.05
50+
£114.63
75+
£113.21
100+
£106.14
200+
£104.72
250+
£103.31
500+
£101.89
1000+
£99.06
Share this product
Description
Description
|
RHP MFC Series Heavy Duty 4 Bolt Round Cast Iron Housing Units: Four bolt round cast iron bearing unit supplied with a sealed full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 50.8mm = 2 inch
- Style:
- MFC
- Pitch Circle Diameter:
- 136.53mm = 5.375 (5-3/8) inch
Technical
Technical
| Bore | 2 inch |
|---|---|
| L | 6.374 inch |
| H | 4.5 inch |
| J | 5.375 inch |
| G | 0.4375 inch |
| A1 | 1.562 inch |
| A4 | 0.748 inch |
| A5 | 0.252 inch |
| B | 2.187 inch |
| s | 0.877 inch |
| d1 | 2.709 inch |
| Dynamic load | 43500 N |
| Static load | 29200 N |
| Rec max speed | 3100 rpm |
| Weight | 3 kg |
| Insert | <a href="advanced_search_result.php?keywords=1055-2G+insonly">1055-2G Click Here</a> |
| Casting group | 5 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
