P16-3M-09F - 3mm Pitch 16 Tooth Flanged HTD Type Aluminium Pilot Bore Timing Pulley for 9mm Wide Belts

HTD Pilot Bore Timing Pulley: High Torque Drive (HTD) timing pulleys are available in both taper and pilot bore. The pulleys depending on the size are made from either Aluminium 6082, C45 Steel with black oxide treated surface or Cast Iron EN-GJL-200 and black phosphate. Where applicable flanges are made from S235JR Steel. Timing belt life can be increased with the proper pulley reducing running costs of your machinery.
Benefits: Available in a wide range of diameters and number of teeth along with standard widths.

Brand / Quality:

Major Brand - High Quality

Number of Teeth:

16

Pitch:

3mm

Item Type:

Pilot Bore Pulley

Maximum Belt Width:

9mm
