SKU: H311-FAG
FAG H311 Adaptor Sleeve with Lock Nut and Locking Device for 50mm Shaft
FAG H311 Adaptor Sleeve with Lock Nut and Locking Device for 50mm Shaft
Regular price
£22.06
ex VAT£26.47inc. VAT
Regular price
Sale price
£22.06
ex VAT£26.47
inc. VAT
In stock
Price Break
10+
£19.63
19+
£18.53
29+
£18.31
39+
£18.09
49+
£17.87
74+
£17.65
99+
£16.55
199+
£16.32
249+
£16.10
499+
£15.88
999+
£15.44
Couldn't load pickup availability
Description
Description
|
Adaptor Sleeves: Are the most commonly used components for locating bearings with a tapered bore onto a cylindrical seating. They can be used on plain shafts allowing the bearing to be positioned as required and locked into place or on stepped shafts with a seating ring to set the bearing off a shoulder before locking it into position Benefits: Re-useable, adjustable, positive location, easy to dismount |
- Brand / Quality:
- FAG - High Quality
- Inside Diameter:
- 50mm
- Outside Diameter:
- 75mm
- Width:
- 45mm
Technical
Technical
| --- | Dimensions |
|---|---|
| d1 | 50mm |
| d | 55mm |
| d3 | 75mm |
| B1 | 45mm |
| B2 | 12.5mm |
| G | Thread 55x2mm |
| Weight | 0.336 kg |
| --- | Assembly Parts |
| Sleeve | H311 |
| Nut | KM11 |
| Washer | MB11 |
| --- | Matching Self Aligning Bearings |
| Bearing No. | <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=2211K+taper+self+open>2211K</a> |
| Bearing No. | <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=1311K+taper+self+open>1311K</a> |
| --- | Matching Spherical Roller Bearings |
| Bearing No. | <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=22211K+taper>22211K</a> |
| Bearing No. | <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=21311K+taper>21311K</a> |
