SKU: FYTJ45TF-SKF
SKF FYTJ45TF Oval Cast Housing with Grub Screw 45mm Insert
SKF FYTJ45TF Oval Cast Housing with Grub Screw 45mm Insert
Regular price
£81.45
ex VAT£97.74inc. VAT
Regular price
Sale price
£81.45
ex VAT£97.74
inc. VAT
In stock
Price Break
10+
£72.49
20+
£68.42
30+
£67.60
40+
£66.79
50+
£65.97
75+
£65.16
100+
£61.09
200+
£60.27
250+
£59.46
500+
£58.64
1000+
£57.02
Description
Description
|
SKF Oval Flanged Y-bearing Units with Cast Housing: These units have an oval flange and two holes for attachment bolts. A grease fitting in the housing allows the unit to be re-lubricated. This makes them especially suitable for bearing arrangements that operate under high levels of contamination, high speeds, high temperatures or relatively heavy loads. Benefits: Grease fitting allows re-lubrication |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 45mm
- Style:
- FYTJ
- Bolt Hole Centres:
- 148mm
Technical
Technical
| d | 45mm |
|---|---|
| A1 | 38mm |
| A2 | 18mm |
| B | 49.2mm |
| Da | 98.4mm |
| H | 188mm |
| J | 148mm |
| L | 108mm |
| N | 19mm |
| G | 16mm |
| s1 | 30.2mm |
| T | 52.2mm |
| Static load Cr | 21.6 kN |
| Dynamic load Cor | 33.2 kN |
| Fatigue load limit Pu | 0.916 kN |
| Limiting speed | 4300 rpm |
| Weight | 2.2 kg |
