SKU: FYTB12TF-SKF
SKF FYTB12TF Oval Cast Housing with Grub Screw 12mm Insert
SKF FYTB12TF Oval Cast Housing with Grub Screw 12mm Insert
Regular price
£34.61
ex VAT£41.53inc. VAT
Regular price
Sale price
£34.61
ex VAT£41.53
inc. VAT
In stock
Price Break
10+
£30.80
20+
£29.07
30+
£28.73
40+
£28.38
50+
£28.03
75+
£27.69
100+
£25.96
200+
£25.61
250+
£25.27
500+
£24.92
1000+
£24.23
Description
Description
|
SKF Oval Flanged Y-bearing Units with Cast Housing: These units have an oval flange and two holes for attachment bolts. A grease fitting in the housing allows the unit to be re-lubricated. This makes them especially suitable for bearing arrangements that operate under high levels of contamination, high speeds, high temperatures or relatively heavy loads. Benefits: Grease fitting allows re-lubrication |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 12mm
- Style:
- FYTB
- Bolt Hole Centres:
- 76.5mm
Technical
Technical
| d | 12mm |
|---|---|
| A1 | 26mm |
| A2 | 11mm |
| B | 27.4mm |
| Da | 50.8mm |
| H | 98.5mm |
| J | 76.5mm |
| L | 57mm |
| N | 11.5mm |
| G | 10mm |
| s1 | 15.9mm |
| T | 32.9mm |
| Static load Cr | 4.75 kN |
| Dynamic load Cor | 9.56 kN |
| Fatigue load limit Pu | 0.2 kN |
| Limiting speed | 9500 rpm |
| Weight | 0.42 kg |
