• SKF C2215K Carb Toroidal Roller Bearing with Taper Bore 75x130x31mm Allow 7-10 Days
1 1

SKU: C2215K-SKF

SKF C2215K Carb Toroidal Roller Bearing with Taper Bore 75x130x31mm Allow 7-10 Days

SKF C2215K Carb Toroidal Roller Bearing with Taper Bore 75x130x31mm Allow 7-10 Days
£336.73 ex VAT£404.08inc. VAT
£336.73 ex VAT£404.08 inc. VAT
Sale Sold out

In stock

Price Break
10+ £299.69
19+ £282.86
29+ £279.49
39+ £276.12
49+ £272.75
74+ £269.39
99+ £252.55
199+ £249.18
249+ £245.81
499+ £242.45
999+ £235.71
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Carb Toroidal Roller Bearings: These compact design bearings have a single row of barrel shaped (spherical) rollers which run on a common spherical outer and inner raceway. Their design offers many features such as self alignment, insensitivity to misalignment, tolerance to heavy radial and axial loads etc. They are manufactured with in both parallel and tapered bore variants and the ability to deliberately displace the position of the rings to each other permits accurate setting of the radial internal clearance.
Benefits: High radial and axial loads, misalignment, taper and parallel bore options
Brand / Quality:
SKF - High Quality
Inside Diameter:
75mm
Outside Diameter:
130mm
Width:
31mm
Seals / Shields:
None
Technical
--- Dimensions
d 75mm
D 130mm
B 31mm
d2 88.5mm
D1 115mm
r1r2 min 1.5mm
s1 9.6mm
da min 84mm
da max 98mm
Da min 110mm
Da max 121mm
Ca 1.2mm
ra max 1.5mm
--- Speeds and Loads
Dynamic load C 196 kN
Static load Co 208 kN
Fatigue load limit Pu 25.5 kN
Reference speed 4800 rpm
Limiting speed 6700 rpm
--- Factors
Misalignment factor k1 0.099
Operating clearance factor k2 0.127
--- Weights
Weight 1.6 kg
--- Matching Adaptor Sleeves
Sleeve No. <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=H315E+sleeve>H315E</a>
Sleeve No. <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=HA315E+sleeve>HA315E</a>
Sleeve No. <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=HE315E+sleeve>HE315E</a>
--- Matching Withdrawal Sleeves
Sleeve No. <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=AH315G+sleeve>AH315G</a>
