SKU: 7908A5TRV1VDULP3-NSK

NSK 7908A5TRV1VDULP3 Super Precision Sealed Angular Contact Spindle Bearing 40x62x12mm (Set of 2)

NSK 7908A5TRV1VDULP3 Super Precision Sealed Angular Contact Spindle Bearing 40x62x12mm (Set of 2)
Regular price £352.36 ex VAT£422.83inc. VAT
Regular price Sale price £352.36 ex VAT£422.83 inc. VAT
Sale Sold out

In stock

Price Break
3+ £313.60
5+ £295.98
10+ £292.46
25+ £288.93
49+ £285.41
74+ £281.89
99+ £264.27
199+ £260.75
249+ £257.22
499+ £253.70
999+ £246.65
Quantity
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Technical
--- Bearing dimensions
d 40mm
D 62mm
B 12mm
r<sub>min</sub> 0.6mm
r1<sub>min</sub> 0.3mm
--- Loads angles and speeds
C<sub>r</sub> 15Kn
C<sub>or</sub> 11.2kN
Axial load Kn 8.9 kN
Contact angle 25 degrees
Factor f<sub>o</sub> -
Effective diameter 17.9mm
Max speed in grease 19700 rpm
Max speed in oil 29500 rpm
--- Fitting dimensions
d<sub>a min</sub> 45mm
D<sub>a max</sub> 57mm
D<sub>b max</sub> 59.5mm
r<sub>a max</sub> 0.6mm
r<sub>b max</sub> 0.3mm
Weight 0.22kg
