SKU: 75AT5/480
75AT5/480 ContiTech Standard Synchroflex Timing Belt 75mm Width 5mm Pitch 96 Teeth
75AT5/480 ContiTech Standard Synchroflex Timing Belt 75mm Width 5mm Pitch 96 Teeth
Regular price
£79.68
ex VAT£95.62inc. VAT
Regular price
Sale price
£79.68
ex VAT£95.62
inc. VAT
In stock
Price Break
3+
£70.92
5+
£66.93
10+
£66.14
15+
£65.34
20+
£64.54
30+
£63.75
40+
£59.76
50+
£58.97
60+
£58.17
75+
£57.37
100+
£55.78
Description
Description
AT Standard SYNCHROFLEX® Timing Belts: This belt is manufactured by ContiTech, specialists in rubber and plastics technology. This Synchroflex belt is a truly endless belt, suitable for AT pulleys.
Standard Synchroflex belts consist of just two components, a wear-resistant Contilan carcass and high-grade endless steel wire tension members. This construction provides high flank load capacity and low elastic elongation which makes them unsurpassed for quality and accuracy.
Benefits: High power AT profile, low elastic elongation and high flank load capacity.
- Brand / Quality:
- ContiTech - High Quality
- Thickness:
- 1.5mm
- Belt Width Approx:
- 75mm
- Belt Length Approx:
- 480mm
- Number of Teeth:
- 96
- Item Type:
- AT5 Standard Timing Belt
Technical
Technical
| No of Teeth | 96 |
|---|---|
| Belt Width | 75mm |
| Belt Pitch | 5mm (AT5) |
| Belt Length | 480mm |
| Belt Thickness (hs) | 1.5mm |
| Tooth Height (ht) | 1.2mm |
| Tooth Pitch (t) | 5mm |
| Flank Angle (f) | 50 deg |
| Tension Member Loadings | 6370 N |
| Belt Weight (per metre) | 0.255kg |
