SKU: 7012CTRV1VSULP3-NSK

NSK 7012CTRV1VSULP3 Super Precision Sealed Angular Contact Spindle Bearing 60x95x18mm

NSK 7012CTRV1VSULP3 Super Precision Sealed Angular Contact Spindle Bearing 60x95x18mm
Regular price £277.98 ex VAT£333.58inc. VAT
Regular price Sale price £277.98 ex VAT£333.58 inc. VAT
Sale Sold out

In stock

Price Break
3+ £247.40
5+ £233.50
10+ £230.72
25+ £227.94
49+ £225.16
74+ £222.38
99+ £208.48
199+ £205.70
249+ £202.92
499+ £200.14
999+ £194.58
Quantity
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Technical
--- Bearing dimensions
d 60mm
D 95mm
B 18mm
r<sub>min</sub> 1.1mm
r1<sub>min</sub> 0.6mm
--- Loads angles and speeds
C<sub>r</sub> 37Kn
C<sub>or</sub> 30.5kN
Axial load Kn 19.9 kN
Contact angle 15 degrees
Factor f<sub>o</sub> 15.7
Effective diameter 19.4mm
Max speed in grease 14900 rpm
Max speed in oil 22600 rpm
--- Fitting dimensions
d<sub>a min</sub> 67mm
D<sub>a max</sub> 88mm
D<sub>b max</sub> 90mm
r<sub>a max</sub> 1mm
r<sub>b max</sub> 0.6mm
Weight 0.405kg
