SKU: 7012CTRV1VDULP3-NSK

NSK 7012CTRV1VDULP3 Super Precision Sealed Angular Contact Spindle Bearing 60x95x18mm (Set of 2)

NSK 7012CTRV1VDULP3 Super Precision Sealed Angular Contact Spindle Bearing 60x95x18mm (Set of 2)
Regular price £538.28 ex VAT£645.94inc. VAT
Regular price Sale price £538.28 ex VAT£645.94 inc. VAT
Sale Sold out

In stock

Price Break
3+ £479.07
5+ £452.16
10+ £446.78
25+ £441.39
49+ £436.01
74+ £430.63
99+ £403.71
199+ £398.33
249+ £392.95
499+ £387.56
999+ £376.80
Quantity
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Technical
--- Bearing dimensions
d 60mm
D 95mm
B 18mm
r<sub>min</sub> 1.1mm
r1<sub>min</sub> 0.6mm
--- Loads angles and speeds
C<sub>r</sub> 37Kn
C<sub>or</sub> 30.5kN
Axial load Kn 19.9 kN
Contact angle 15 degrees
Factor f<sub>o</sub> 15.7
Effective diameter 19.4mm
Max speed in grease 14900 rpm
Max speed in oil 22600 rpm
--- Fitting dimensions
d<sub>a min</sub> 67mm
D<sub>a max</sub> 88mm
D<sub>b max</sub> 90mm
r<sub>a max</sub> 1mm
r<sub>b max</sub> 0.6mm
Weight 0.81kg
