SKU: 7012CTRQUMP3-NSK

NSK 7012CTRQUMP3 Super Precision Angular Contact Spindle Bearing 60x95x18mm (Set of 4)

NSK 7012CTRQUMP3 Super Precision Angular Contact Spindle Bearing 60x95x18mm (Set of 4)
Regular price £854.66 ex VAT£1,025.59inc. VAT
Regular price Sale price £854.66 ex VAT£1,025.59 inc. VAT
Sale Sold out

In stock

Price Break
3+ £760.65
5+ £717.91
10+ £709.37
25+ £700.82
49+ £692.27
74+ £683.73
99+ £640.99
199+ £632.45
249+ £623.90
499+ £615.35
999+ £598.26
Quantity
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Technical
--- Bearing dimensions
d 60mm
D 95mm
B 18mm
r<sub>min</sub> 1.1mm
r1<sub>min</sub> 0.6mm
--- Loads angles and speeds
C<sub>r</sub> 37Kn
C<sub>or</sub> 30.5kN
Axial load Kn 19.9 kN
Contact angle 15 degrees
Factor f<sub>o</sub> 15.7
Effective diameter 19.4mm
Max speed in grease 14900 rpm
Max speed in oil 22600 rpm
--- Fitting dimensions
d<sub>a min</sub> 67mm
D<sub>a max</sub> 88mm
D<sub>b max</sub> 90mm
r<sub>a max</sub> 1mm
r<sub>b max</sub> 0.6mm
Weight 1.62kg
