SKU: 7011A5TRV1VDULP2-NSK

NSK 7011A5TRV1VDULP2 Super Precision Sealed Angular Contact Spindle Bearing 55x90x18mm (Set of 2)

NSK 7011A5TRV1VDULP2 Super Precision Sealed Angular Contact Spindle Bearing 55x90x18mm (Set of 2)
Regular price £686.73 ex VAT£824.08inc. VAT
Regular price Sale price £686.73 ex VAT£824.08 inc. VAT
Sale Sold out

In stock

Price Break
3+ £611.19
5+ £576.85
10+ £569.98
25+ £563.11
49+ £556.25
74+ £549.38
99+ £515.04
199+ £508.18
249+ £501.31
499+ £494.44
999+ £480.71
Quantity
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Technical
--- Bearing dimensions
d 55mm
D 90mm
B 18mm
r<sub>min</sub> 1.1mm
r1<sub>min</sub> 0.6mm
--- Loads angles and speeds
C<sub>r</sub> 34Kn
C<sub>or</sub> 27.2kN
Axial load Kn 21.8 kN
Contact angle 25 degrees
Factor f<sub>o</sub> -
Effective diameter 25.9mm
Max speed in grease 13800 rpm
Max speed in oil 20700 rpm
--- Fitting dimensions
d<sub>a min</sub> 62mm
D<sub>a max</sub> 83mm
D<sub>b max</sub> 85mm
r<sub>a max</sub> 1mm
r<sub>b max</sub> 0.6mm
Weight 0.766kg
