SKU: 6303NR-MB
6303NR Deep Groove Ball Bearing with Snap Ring 17x47x14mm
6303NR Deep Groove Ball Bearing with Snap Ring 17x47x14mm
Regular price
£14.83
ex VAT£17.80inc. VAT
Regular price
Sale price
£14.83
ex VAT£17.80
inc. VAT
In stock
Price Break
10+
£13.20
19+
£12.46
29+
£12.31
39+
£12.16
49+
£12.01
74+
£11.86
99+
£11.12
199+
£10.97
249+
£10.82
499+
£10.68
999+
£10.38
Description
Description
|
Deep Groove Ball Bearings with Snap Ring: A popular choice where the housings is part of a machine frame casing, these bearing types are manufactured without seals to allow the circulation of the oil or grease lubricant. The snap ring is made from a spring steel material and fits into an annular groove around the outside of the bearing which is offset to one side. |
- Brand / Quality:
- Major Brand - High Quality
- Inside Diameter:
- 17mm
- Outside Diameter:
- 47mm
- Width:
- 14mm
- Seals / Shields:
- None
- Clearance:
- * Standard
Technical
Technical
| d | 17mm |
|---|---|
| D | 47mm |
| B | 14mm |
| Dyamic load C | 14.3 kN |
| Static load Co | 6.55 kN |
| Fatigue load limit Pu | 0.275 kN |
| Reference speed | 34000 rpm |
| Limiting speed | 22000 rpm |
| Mass | 0.12 kg |
| d1 | 26.5mm |
| d2 | 37.4mm |
| D2 | 39.7mm |
| r1r2 min | 1mm |
| da min | 22.6 |
