SKU: 6201C3-NSK
NSK 6201C3 Open Type Deep Groove Ball Bearing 12x32x10mm
NSK 6201C3 Open Type Deep Groove Ball Bearing 12x32x10mm
Regular price
£3.50
ex VAT£4.20inc. VAT
Regular price
Sale price
£3.50
ex VAT£4.20
inc. VAT
In stock
Price Break
4+
£3.11
10+
£2.94
20+
£2.90
30+
£2.87
50+
£2.83
75+
£2.80
100+
£2.62
200+
£2.59
250+
£2.55
500+
£2.52
1000+
£2.45
Description
Description
Open Deep Groove Ball Bearings: One of the most commonly used bearings, the open types are manufactured without seals to allow for the free circulation of either oil or grease, used in gearboxes and other environments where no foreign matter would be present and a lubricant supply is available.
Benefits: Used widely in transmissions etc, can be used in oil or greased, cost-effective solution.
- Brand / Quality:
- NSK - High Quality
- Inside Diameter:
- 12mm
- Outside Diameter:
- 32mm
- Width:
- 10mm
- Seals / Shields:
- None
- Clearance:
- C3
Technical
Technical
| d | 12mm |
|---|---|
| D | 32mm |
| B | 10mm |
| r min | 0.6mm |
| Dynamic load Cr | 6800 N (695 kgf) |
| Static load Cor | 3050 N (310 kgf) |
| Factor | 12.3 |
| Speed in grease | 22000 rpm |
| Speed in oil | 28000 rpm |
| Mass | 0.037 kg |
