SKF 53220 Single Thrust Ball Bearing with Spherical Housing Seat U220 100x150x45mm
SKF 53220 Single Thrust Ball Bearing with Spherical Housing Seat U220 100x150x45mm
Regular price
£387.10
ex VAT£464.52inc. VAT
Regular price
Sale price
£387.10
ex VAT£464.52
inc. VAT
In stock
Price Break
10+
£363.88
19+
£356.14
29+
£344.52
39+
£336.78
49+
£332.91
74+
£325.17
99+
£313.55
199+
£305.81
249+
£301.94
499+
£294.20
999+
£290.33
Share this product
Description
Description
|
SKF Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. (shown but available separately). Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 100mm
- Outside Diameter:
- 150mm
- Width:
- 45mm
Technical
Technical
| d | 100mm |
|---|---|
| D | 150mm |
| H1 | 45mm |
| Dynamic load C | 124 kN |
| Static load Co | 345 kN |
| Fatigue load limit Pu | 11.4 kN |
| Minimum load factor A | 0.62 |
| Reference speed | 1800 rpm |
| Limiting speed | 2400 rpm |
| Weight | 2.7 kg |
| Seating washer | U220 |
| d1 | 150mm |
| D1 | 103mm |
| D2 | 125mm |
| D3 | 155mm |
| H | 40.9mm |
| C | 14mm |
| R | 112mm |
| s | 52mm |
| r1r2 min | 1.1mm |
| da max | 130mm |
| Da max | 125mm |
| ra max | 1mm |
