SKF 53211 Single Thrust Ball Bearing with Spherical Housing Seat U211 55x90x30mm
SKF 53211 Single Thrust Ball Bearing with Spherical Housing Seat U211 55x90x30mm
Regular price
£143.94
ex VAT£172.73inc. VAT
Regular price
Sale price
£143.94
ex VAT£172.73
inc. VAT
In stock
Price Break
10+
£128.11
19+
£120.91
29+
£119.47
39+
£118.03
49+
£116.59
74+
£115.15
99+
£107.96
199+
£106.52
249+
£105.08
499+
£103.64
999+
£100.76
Share this product
Description
Description
|
SKF Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. (shown but available separately). Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 55mm
- Outside Diameter:
- 90mm
- Width:
- 30mm
Technical
Technical
| d | 55mm |
|---|---|
| D | 90mm |
| H1 | 30mm |
| Dynamic load C | 61.8 kN |
| Static load Co | 146 kN |
| Fatigue load limit Pu | 5.4 kN |
| Minimum load factor A | 0.11 |
| Reference speed | 2800 rpm |
| Limiting speed | 4000 rpm |
| Weight | 0.75 kg |
| Seating washer | U211 |
| d1 | 90mm |
| D1 | 57mm |
| D2 | 72mm |
| D3 | 95mm |
| H | 27.35mm |
| C | 9mm |
| R | 72mm |
| s | 35mm |
| r1r2 min | 1mm |
| da max | 76mm |
| Da max | 72mm |
| ra max | 1mm |
