• SKF 51102 Single Thrust Ball Bearing 15x28x9mm
1 1

SKU: 51102-SKF

SKF 51102 Single Thrust Ball Bearing 15x28x9mm

SKF 51102 Single Thrust Ball Bearing 15x28x9mm
£13.27 ex VAT£15.92inc. VAT
£13.27 ex VAT£15.92 inc. VAT
Sale Sold out

In stock

Price Break
10+ £11.81
19+ £11.15
29+ £11.02
39+ £10.88
49+ £10.75
74+ £10.62
99+ £9.95
199+ £9.82
249+ £9.69
499+ £9.56
999+ £9.29
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
SKF Thrust Ball Thrust Bearings: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment.
Benefits: Axial loading, ease of mounting and assembly
Brand / Quality:
SKF - High Quality
Inside Diameter:
15mm
Outside Diameter:
28mm
Width:
9mm
Technical
d 15mm
D 28mm
H 9mm
Dynamic load C 10.6 kN
Static load Co 18.3 kN
Fatigue load limit Pu 0.67 kN
Minimum load factor A 0.0017
Reference speed 8500 rpm
Limiting speed 12000 rpm
Weight 0.023 kg
d1 28mm
D1 16mm
r1r2 min 0.3mm
da min 23mm
Da max 20mm
ra max 0.3mm
