SKU: 50AT10/1150
50AT10/1150 ContiTech Standard Synchroflex Timing Belt 50mm Width 10mm Pitch 115 Teeth
50AT10/1150 ContiTech Standard Synchroflex Timing Belt 50mm Width 10mm Pitch 115 Teeth
Regular price
£120.49
ex VAT£144.59inc. VAT
Regular price
Sale price
£120.49
ex VAT£144.59
inc. VAT
In stock
Price Break
10+
£107.24
19+
£101.21
29+
£100.01
39+
£98.80
49+
£97.60
74+
£96.39
99+
£90.37
199+
£89.16
249+
£87.96
499+
£86.75
999+
£84.34
Couldn't load pickup availability
Description
Description
AT Standard SYNCHROFLEX® Timing Belts: This belt is manufactured by ContiTech, specialists in rubber and plastics technology. This Synchroflex belt is a truly endless belt, suitable for AT pulleys.
Standard Synchroflex belts consist of just two components, a wear-resistant Contilan carcass and high-grade endless steel wire tension members. This construction provides high flank load capacity and low elastic elongation which makes them unsurpassed for quality and accuracy.
Benefits: High power AT profile, low elastic elongation and high flank load capacity.
- Brand / Quality:
- ContiTech - High Quality
- Thickness:
- 2.5mm
- Belt Width Approx:
- 50mm
- Belt Length Approx:
- 1150mm
- Number of Teeth:
- 115
- Item Type:
- AT10 Standard Timing Belt
Technical
Technical
| No of Teeth | 115 |
|---|---|
| Belt Width | 50mm |
| Belt Pitch | 10mm (AT10) |
| Belt Length | 1150mm |
| Belt Thickness (hs) | 2.5mm |
| Tooth Height (ht) | 2.5mm |
| Tooth Pitch (t) | 10mm |
| Flank Angle (f) | 50 deg |
| Tension Member Loadings | 7750 N |
| Belt Weight (per metre) | 0.315kg |
