SKU: 50-1-SYN-NO30-RENOLD
Renold Synergy 50-1-NO30 ANSI / AS Simplex Chain Double Cranked Link 5/8 inch Pitch
Renold Synergy 50-1-NO30 ANSI / AS Simplex Chain Double Cranked Link 5/8 inch Pitch
Regular price
£25.38
ex VAT£30.46inc. VAT
Regular price
Sale price
£25.38
ex VAT£30.46
inc. VAT
In stock
Price Break
10+
£22.59
19+
£21.32
29+
£21.07
39+
£20.81
49+
£20.56
74+
£20.30
99+
£19.04
199+
£18.78
249+
£18.53
499+
£18.27
999+
£17.77
Couldn't load pickup availability
Description
Description
| Renold No. 30 ANSI Simplex Connecting Link: Double cranked links are available for most sizes and types of chain. The unit consists of an inner link (No. 4), with cranked links retained permanently in position by a riveted bearing pin. |
- Brand / Quality:
- Renold - High Quality
- Pitch:
- 15.88mm = 0.625 (5/8) inch
Technical
Technical
| Pitch (A) | 0.625 inch |
|---|---|
| Pitch (A) | 15.875mm |
| Inside Width min (B) | 9.4mm |
| Roller Diameter max (C) | 10.16mm |
| Plate Height max (D) | 14.6mm |
| Plate Width Inner max (E) | 2.04mm |
| Plate Width Outer max (F) | 2.04mm |
| Pin Diameter max (G) | 5.08mm |
| Pin Length max (H1) | 20.4mm |
| Connecting Link Extension max (J) | 2.7mm |
| ISO606 Tensile Strength min | 21800 N |
| Weight | 0.015kg/m |
