SKU: 20B-1-SYNO-10FT-RENOLD
Renold SYNO 20B-1 BS Simplex Roller Chain 1-1/4mm Pitch - 10 Feet Length
Renold SYNO 20B-1 BS Simplex Roller Chain 1-1/4mm Pitch - 10 Feet Length
Regular price
£1,317.06
ex VAT£1,580.47inc. VAT
Regular price
Sale price
£1,317.06
ex VAT£1,580.47
inc. VAT
Equivalent to: SNX20B-1
In stock
Price Break
10+
£1,172.18
19+
£1,106.33
29+
£1,093.16
39+
£1,079.99
49+
£1,066.82
74+
£1,053.65
99+
£987.80
199+
£974.62
249+
£961.45
499+
£948.28
999+
£921.94
Couldn't load pickup availability
Description
Description
Renold SYNO Maintenace-free Corrosion-resistant Simplex Chain: Renold Syno Nickel Plated chain is ideal for situations where lubricant is to be avoided. Particularly in hygiene-sensitive applications. With a food industry-approved lubricant contained within its sintered bush, this chain needs no relubricating in practically every environment. The roller coating, unique to Renold, is especially suited to the food industry.
Equivalent: SNX20B-1
- Brand / Quality:
- Renold - High Quality
- Pitch:
- 31.75mm = 1.25 (1-1/4) inch
Technical
Technical
| Pitch (A) | 1.25 inch |
|---|---|
| Pitch (A) | 31.75mm |
| Inside Width min (B) | 19.56mm |
| Roller Diameter max (C) | 19.05mm |
| Plate Height max (D) | 26.42mm |
| Plate Width Inner max (E) | 4.62mm |
| Plate Width Outer max (F) | 3.61mm |
| Pin Diameter max (G) | 10.19mm |
| Pin Length max (H1) | 39.8mm |
| Connecting link extension max (J) | 2.7mm |
| ISO606 Tensile strength min | 95000 N |
| Weight | 3.85 kg/m |
