SKU: 100AT5/780
100AT5/780 ContiTech Standard Synchroflex Timing Belt 100mm Width 5mm Pitch 156 Teeth
100AT5/780 ContiTech Standard Synchroflex Timing Belt 100mm Width 5mm Pitch 156 Teeth
Regular price
£144.59
ex VAT£173.51inc. VAT
Regular price
Sale price
£144.59
ex VAT£173.51
inc. VAT
In stock
Price Break
3+
£128.68
5+
£121.45
10+
£120.01
15+
£118.56
20+
£117.11
30+
£115.67
40+
£108.44
50+
£106.99
60+
£105.55
75+
£104.10
100+
£101.21
Description
Description
AT Standard SYNCHROFLEX® Timing Belts: This belt is manufactured by ContiTech, specialists in rubber and plastics technology. This Synchroflex belt is a truly endless belt, suitable for AT pulleys.
Standard Synchroflex belts consist of just two components, a wear-resistant Contilan carcass and high-grade endless steel wire tension members. This construction provides high flank load capacity and low elastic elongation which makes them unsurpassed for quality and accuracy.
Benefits: High power AT profile, low elastic elongation and high flank load capacity.
- Brand / Quality:
- ContiTech - High Quality
- Thickness:
- 1.5mm
- Belt Width Approx:
- 100mm
- Belt Length Approx:
- 780mm
- Number of Teeth:
- 156
- Item Type:
- AT5 Standard Timing Belt
Technical
Technical
| No of Teeth | 156 |
|---|---|
| Belt Width | 100mm |
| Belt Pitch | 5mm (AT5) |
| Belt Length | 780mm |
| Belt Thickness (hs) | 1.5mm |
| Tooth Height (ht) | 1.2mm |
| Tooth Pitch (t) | 5mm |
| Flank Angle (f) | 50 deg |
| Tension Member Loadings | 8610 N |
| Belt Weight (per metre) | 0.34kg |
