SKU: 100AT10/560
100AT10/560 ContiTech Standard Synchroflex Timing Belt 100mm Width 10mm Pitch 56 Teeth
100AT10/560 ContiTech Standard Synchroflex Timing Belt 100mm Width 10mm Pitch 56 Teeth
Regular price
£138.16
ex VAT£165.79inc. VAT
Regular price
Sale price
£138.16
ex VAT£165.79
inc. VAT
In stock
Price Break
3+
£122.96
5+
£116.05
10+
£114.67
15+
£113.29
20+
£111.91
30+
£110.53
40+
£103.62
50+
£102.24
60+
£100.86
75+
£99.47
100+
£96.71
Description
Description
AT Standard SYNCHROFLEX® Timing Belts: This belt is manufactured by ContiTech, specialists in rubber and plastics technology. This Synchroflex belt is a truly endless belt, suitable for AT pulleys.
Standard Synchroflex belts consist of just two components, a wear-resistant Contilan carcass and high-grade endless steel wire tension members. This construction provides high flank load capacity and low elastic elongation which makes them unsurpassed for quality and accuracy.
Benefits: High power AT profile, low elastic elongation and high flank load capacity.
- Brand / Quality:
- ContiTech - High Quality
- Thickness:
- 2.5mm
- Belt Width Approx:
- 100mm
- Belt Length Approx:
- 560mm
- Number of Teeth:
- 56
- Item Type:
- AT10 Standard Timing Belt
Technical
Technical
| No of Teeth | 56 |
|---|---|
| Belt Width | 100mm |
| Belt Pitch | 10mm (AT10) |
| Belt Length | 560mm |
| Belt Thickness (hs) | 2.5mm |
| Tooth Height (ht) | 2.5mm |
| Tooth Pitch (t) | 10mm |
| Flank Angle (f) | 50 deg |
| Tension Member Loadings | 16000 N |
| Belt Weight (per metre) | 0.63kg |
