SKU: SSUCF.205-16
SSUCF205-16 Imperial Four Bolt Square Stainless Steel Flange Housing with 1 inch Bore Stainless Insert
SSUCF205-16 Imperial Four Bolt Square Stainless Steel Flange Housing with 1 inch Bore Stainless Insert
Regular price
£14.63
ex VAT£17.56inc. VAT
Regular price
Sale price
£14.63
ex VAT£17.56
inc. VAT
In stock
Price Break
3+
£13.02
4+
£12.29
9+
£12.14
19+
£12.00
49+
£11.85
99+
£11.70
499+
£10.97
999+
£10.83
1999+
£10.68
2999+
£10.53
4999+
£10.24
Description
Description
|
UCF or SF Series Stainless Steel 4 Bolt Square Housings: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 25.4mm = 1 inch
- Style:
- SSUCF
- Bolt Hole Centres:
- 70mm
Technical
Technical
| d | 1 inch |
|---|---|
| a | 95mm |
| e | 70mm |
| i | 16mm |
| g | 14mm |
| L | 27mm |
| S | 12mm |
| Z | 35.7mm |
| Bi | 34mm |
| n | 14.3mm |
| Bolt | 10mm |
| Weight | 0.82 kg |
| Dynamic load | 1100 kgf |
| Static load | 710 kgf |
