SKU: NU324ECM/C3VL0241-SKF
SKF NU324ECMC3VL0241 Insocoat Cylindrical Roller Bearing 120x260x55mm
SKF NU324ECMC3VL0241 Insocoat Cylindrical Roller Bearing 120x260x55mm
Regular price
£2,143.76
ex VAT£2,572.51inc. VAT
Regular price
Sale price
£2,143.76
ex VAT£2,572.51
inc. VAT
In stock
Price Break
10+
£1,907.95
19+
£1,800.76
29+
£1,779.32
39+
£1,757.88
49+
£1,736.45
74+
£1,715.01
99+
£1,607.82
199+
£1,586.38
249+
£1,564.95
499+
£1,543.51
999+
£1,500.63
Share this product
Description
Description
|
SKF Insocoat Bearings: Special application bearings that are electrically insulated and capable of withstanding voltages up to 1000v, a layer of aluminium oxide (100µm thickness) Benefits: Electrically insulated |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 120mm
- Outside Diameter:
- 260mm
- Width:
- 55mm
- Seals / Shields:
- None
- Clearance:
- C3
Technical
Technical
| d | 120mm |
|---|---|
| D | 260mm |
| B | 55mm |
| Dynamic load C | 610 kN |
| Static load Co | 620 kN |
| Fatigue load limit Pu | 69.5 kN |
| Reference speed | 2800 rpm |
| Limiting speed | 3200 rpm |
| Weight | 15.2 kg |
| D1 | 219mm |
| F | 154mm |
| r1r2 min | 3mm |
| r1r4 min | 3mm |
| s | 3.7mm |
| da min | 134mm |
| da max | 150mm |
| db min | 157mm |
| Da min | 225mm |
| Da max | 246mm |
| ra max | 2.5mm |
| rb max | 2.5mm |
| kr | 0.15 |
